APS11700LUAA-0PL
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Position, Proximity, Speed (Modules)
Description
24V MICROPOWER HALL EFFECT SWITC
PDF
/
Buying Options
Total Price: USD $0.78
Unit Price: USD $0.7832
≥1 USD $0.7832
≥10 USD $0.58872
≥100 USD $0.470976
≥500 USD $0.43164
≥1000 USD $0.362947
≥3000 USD $0.3454
Inventory: 7947
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Body Height 4.12mm
Technical
Input Mode OMNIPOLAR
Must Release ±2.25mT
Magnetic Field Range-Max 7 mT
Magnetic Field Range-Min 0.5 mT
Must Operate ±4mT
Hysteresis 1.75 mT
Screening Level AEC-Q100; ISO-26262
Output Type Analog
Body Breadth 1.52 mm
Body Length or Diameter 4.09mm
Voltage - Supply 3.3V~24V
Additional Feature SHORT CIRCUIT PROTECTION
Type Hall Effect Switch
Number of Terminations 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Operating Temperature -40°C~150°C TA
Physical
Actuator Material Magnet
Mounting Feature THROUGH HOLE MOUNT
Surface Mount NO
Package / Case 3-SSIP
Supply Chain
Factory Lead Time 8 Weeks
