PDRV5053VAQLPG
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 Short Body
Category Sensors, Transducers / Magnetic Sensors - Linear, Compass (ICs)
Description
Bulk Analog Voltage Hall Effect Temperature Compensated Hall Effect Sensor 1.52mm 3.6mA 2.5V~38V -40C~125C TA
PDF
/
Inventory: 1567
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 Short Body
Number of Pins 3
Technical
Operating Temperature -40°C~125°C TA
Packaging Bulk
Feature Temperature Compensated
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Additional Feature SHORT CIRCUIT PROTECTION
Technology Hall Effect
Voltage - Supply 2.5V~38V
Base Part Number DRV5053
Current - Supply (Max) 3.6mA
Body Length or Diameter 4mm
Body Breadth 1.52 mm
Output Type Analog Voltage
Max Output Current 2.3mA
Operating Supply Voltage 38V
Termination Type SOLDER
Output Current 2.3mA
Max Supply Current 3.6mA
Bandwidth 20kHz
Linearity 1 %
Sensing Method Hall Effect
Sensing Range ±9mT
Axis Single
Output Range 0-2V
Dimensions
Body Height 5.05mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
