PDRV5053RAQDBZT

Texas Instruments
RoHS
RoHS RoHS compliant
Package TO-236-3, SC-59, SOT-23-3
Category Sensors, Transducers / Magnetic Sensors - Linear, Compass (ICs)
Description Hall Effect Sensor Bipolar 3.3V/5V/9V/12V/15V/18V/24V 3-Pin SOT-23 T/R
PDF
/
Inventory: 6951
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status ROHS3 Compliant

Dimensions

Body Height 1.005mm

Technical

Output Range 0-2V
Axis Single
Sensing Range ±18mT
Housing PLASTIC
Sensing Method Hall Effect
Linearity 1 %
Bandwidth 20kHz
Max Supply Current 3.6mA
Termination Type SOLDER
Max Output Current 2.3mA
Output Type Analog Voltage
Body Length or Diameter 2.92mm
Current - Supply (Max) 3.6mA
Base Part Number DRV5053
Voltage - Supply 2.5V~38V
Technology Hall Effect
Additional Feature SHORT CIRCUIT PROTECTION
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Temperature Compensated
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA

Physical

Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Mount Surface Mount
