PDRV5053PAQLPG
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 Short Body
Category Sensors, Transducers / Magnetic Sensors - Linear, Compass (ICs)
Description
Hall Effect Sensor 2.3mA Bipolar 2.5V to 38V 3-Pin TO-92 T/R
PDF
/
Inventory: 958
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Body Height 5.05mm
Technical
Output Range 0-2V
Axis Single
Sensing Range ±35mT
Sensing Method Hall Effect
Linearity 1 %
Bandwidth 20kHz
Max Supply Current 3.6mA
Output Current 2.3mA
Termination Type SOLDER
Operating Supply Voltage 38V
Max Output Current 2.3mA
Output Type Analog Voltage
Body Breadth 1.52 mm
Body Length or Diameter 4mm
Current - Supply (Max) 3.6mA
Base Part Number DRV5053
Voltage - Supply 2.5V~38V
Technology Hall Effect
Additional Feature SHORT CIRCUIT PROTECTION
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Temperature Compensated
Packaging Bulk
Operating Temperature -40°C~125°C TA
Physical
Package / Case TO-226-3, TO-92-3 Short Body
Mounting Type Through Hole
Mount Through Hole
