DRV5056A4QLPGM
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Sensors, Transducers / Magnetic Sensors - Linear, Compass (ICs)
Description
SENSOR HALL EFFECT ANALOG
PDF
/
Buying Options
Total Price: USD $1.61
Unit Price: USD $1.6112
≥1 USD $1.6112
≥10 USD $1.3224
≥100 USD $1.2806
≥500 USD $1.23975
≥1000 USD $1.19795
Inventory: 1188
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Surface Mount NO
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Feature Temperature Compensated
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature IT ALSO HAS POWER SUPPLY VOLTAGE 4.5 TO 5.5V; IT HAS SENSITIVITY 25 MV/MT
Technology Hall Effect
Voltage - Supply 3V~3.63V 4.5V~5.5V
Base Part Number DRV5056
Current - Supply (Max) 10mA
Body Length or Diameter 4mm
Body Breadth 1.52 mm
Output Type Analog Voltage
Termination Type SOLDER
Current - Output (Max) 1mA
Bandwidth 20kHz
Housing PLASTIC
Sensing Range 158mT
Axis Single
Output Range 0.55-3.1V
Magnetic Field Range-Min 155 mT
Dimensions
Body Height 5.05mm
Compliance
RoHS Status ROHS3 Compliant
