DRV5055A2ELPGMQ1
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Sensors, Transducers / Magnetic Sensors - Linear, Compass (ICs)
Description
Tube Automotive AEC-Q100 Analog Voltage Hall Effect Hall Effect Sensor 1.52mm 1mA 3V~3.63V 4.5V~5.5V -40C~150C TA
PDF
/
Buying Options
Total Price: USD $1.65
Unit Price: USD $1.6544
≥1 USD $1.6544
≥10 USD $1.24256
≥100 USD $0.994048
≥500 USD $0.91124
≥1000 USD $0.766234
≥3000 USD $0.683399
Inventory: 88901
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Surface Mount NO
Technical
Operating Temperature -40°C~150°C TA
Packaging Tube
Series Automotive, AEC-Q100
JESD-609 Code e3
Feature Temperature Compensated
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Terminal Finish Matte Tin (Sn)
Additional Feature AEC-Q100; IT ALSO OPERATES AT 4.5 TO 5.5 V SUPPLY VOLTAGE
Technology Hall Effect
Voltage - Supply 3V~3.63V 4.5V~5.5V
Base Part Number DRV5055
Current - Supply (Max) 10mA
Body Length or Diameter 4mm
Body Breadth 1.52 mm
Output Type Analog Voltage
Termination Type SOLDER
Current - Output (Max) 1mA
Bandwidth 20kHz
Sensing Range ±44mT
Axis Single
Dimensions
Body Height 5.05mm
Compliance
RoHS Status ROHS3 Compliant
