DRV5053PAQLPGMQ1
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 Short Body
Category Sensors, Transducers / Magnetic Sensors - Linear, Compass (ICs)
Description
Tape & Box (TB) Automotive AEC-Q100 COMPLEMENTARY Hall Effect Hall Effect Sensor 5.05mm 3.6mA 2.7V~38V -40C~125C TA
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.565921
≥1 USD $0.565921
≥10 USD $0.533888
≥100 USD $0.503667
≥500 USD $0.475159
≥1000 USD $0.448262
Inventory: 958
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 Short Body
Surface Mount NO
Number of Pins 3
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Box (TB)
Series Automotive, AEC-Q100
JESD-609 Code e3
Feature Temperature Compensated
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature AEC-Q100, SHORT CIRCUIT PROTECTION, REVERSE SUPPLY PROTECTION
Technology Hall Effect
Voltage - Supply 2.7V~38V
Base Part Number DRV5053
Current - Supply (Max) 3.6mA
Output Type Analog Voltage
Max Output Current 2.3mA
Termination Type SOLDER
Max Supply Current 3.6mA
Bandwidth 20kHz
Output Polarity COMPLEMENTARY
Linearity 1 %
Sensing Method Hall Effect
Housing PLASTIC
Sensing Range ±35mT
Axis Single
Input Mode BIPOLAR
Dimensions
Height 5.05mm
Length 4mm
Width 3.15mm
Thickness 1.52mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
