TLE4990HAXA1
RoHS
/
Package 3-SIP, SSO-3-10
Category Sensors, Transducers / Magnetic Sensors - Linear, Compass (ICs)
Description
Hall Effect Sensor 1.2mA Bipolar 5V Automotive 4-Pin SSO Ammo
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.07445
≥1 USD $1.07445
≥10 USD $0.8816
≥100 USD $0.85405
≥500 USD $0.8265
≥1000 USD $0.79895
Inventory: 4012
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 3-SIP, SSO-3-10
Number of Pins 4
Technical
Operating Temperature -40°C~150°C TA
Packaging Tape & Box (TB)
Published 1999
JESD-609 Code e3
Feature Programmable, Temperature Compensated
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Terminal Finish MATTE TIN
Technology Hall Effect
Voltage - Supply 4.5V~5.5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 4
Current - Supply (Max) 5.5mA
Qualification Status Not Qualified
Output Type Analog Voltage
Max Output Current 1.2mA
Operating Supply Voltage 5V
Analog IC - Other Type ANALOG CIRCUIT
Output Current 1.2mA
Max Supply Current 5.5mA
Sensing Method Hall Effect
Sensing Range ±200mT
Axis Single
Dimensions
Height Seated (Max) 3.79mm
Width 1mm
Compliance
RoHS Status RoHS Compliant
