SN74SSTL16837ADGGR
RoHS
RoHS compliant
RoHS compliantPackage 64-TFSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Logic - Universal Bus Functions
Description
GULL WING ENABLE LOW Surface Mount ROHS3Compliant Universal Bus Driver 30pF 0C~70C 20mA 20mA 3V~3.6V
PDF
/
Buying Options
Total Price: USD $74.61
Unit Price: USD $74.61015
≥1 USD $74.61015
≥10 USD $61.218
≥100 USD $59.30565
≥500 USD $57.39235
≥1000 USD $55.47905
Inventory: 2603
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 6.1mm
Length 17mm
Height Seated (Max) 1.2mm
Technical
Power Supply Current-Max (ICC) 90mA
Control Type ENABLE LOW
Prop. Delay@Nom-Sup 4.2 ns
Max I(ol) 0.02 A
Logic Type Universal Bus Driver
Current - Output High, Low 20mA 20mA
Output Characteristics 3-STATE
Direction Unidirectional
Propagation Delay 3.2 ns
Number of Bits 20
Output Current 20mA
Number of Ports 2
Load Capacitance 30pF
Number of Circuits 20-Bit
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Polarity Non-Inverting
Operating Supply Voltage 3.3V
Pin Count 64
Base Part Number 74SSTL16837
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Technology BICMOS
Subcategory Bus Driver/Transceivers
HTS Code 8542.39.00.01
Number of Terminations 64
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74SSTL
Packaging Cut Tape (CT)
Operating Temperature 0°C~70°C
Physical
Weight 259.993477mg
Number of Pins 64
Package / Case 64-TFSOP (0.240, 6.10mm Width)
Mounting Type Surface Mount
Mount Surface Mount
