SN74AVC16834DGVR
RoHS
RoHS compliant
RoHS compliantPackage 56-TFSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Universal Bus Functions
Description
Nickel/Palladium/Gold (Ni/Pd/Au) 18-Bit 74AVC16834 CMOS universal bus function 6ns 11.3mm 1.4V~3.6V 12mA 12mA
PDF
/
Buying Options
Total Price: USD $1.58
Unit Price: USD $1.583681
≥1 USD $1.583681
≥100 USD $1.361663
≥250 USD $0.945915
≥1000 USD $0.751675
Inventory: 21174
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 56-TFSOP (0.173, 4.40mm Width)
Number of Pins 56
Weight 139.989945mg
Technical
Operating Temperature -40°C~85°C
Packaging Cut Tape (CT)
Series 74AVC
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 56
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Bus Driver/Transceivers
Packing Method TR
Technology CMOS
Voltage - Supply 1.4V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 1.5V
Terminal Pitch 0.4mm
Base Part Number 74AVC16834
Pin Count 56
Number of Elements 1
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3.3V
Number of Channels 18
Number of Circuits 18-Bit
Load Capacitance 30pF
Number of Ports 2
Output Current 12mA
Number of Bits 18
Propagation Delay 6 ns
Turn On Delay Time 10.3 ns
Family AVC
Direction Unidirectional
Output Characteristics 3-STATE
Current - Output High, Low 12mA 12mA
Logic Type Universal Bus Driver
Control Type ENABLE LOW
Power Supply Current-Max (ICC) 0.04mA
Translation N/A
Dimensions
Height 1.2mm
Length 11.3mm
Width 4.4mm
Thickness 1.05mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
