SN74AUC16501DGGR
RoHS
RoHS compliant
RoHS compliantPackage 56-TFSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Logic - Universal Bus Functions
Description
GULL WING INDEPENDENT CONTROL Surface Mount ROHS3Compliant Universal Bus Transceiver 15pF -40C~85C 9mA 9mA 0.8V~2.7V
PDF
/
Buying Options
Total Price: USD $1.83
Unit Price: USD $1.82781
≥1 USD $1.82781
≥10 USD $1.724351
≥100 USD $1.626741
≥500 USD $1.534661
≥1000 USD $1.447798
Inventory: 1466
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 6.1mm
Length 14mm
Height Seated (Max) 1.2mm
Technical
Translation N/A
Control Type INDEPENDENT CONTROL
Propagation Delay (tpd) 3.8 ns
Trigger Type POSITIVE EDGE
Prop. Delay@Nom-Sup 4 ns
Max I(ol) 0.005 A
Output Polarity TRUE
Logic Type Universal Bus Transceiver
Current - Output High, Low 9mA 9mA
Output Characteristics 3-STATE
Direction Bidirectional
Logic Function Transceiver
Family AUC
Number of Bits 18
Number of Ports 2
Load Capacitance 15pF
Number of Circuits 18-Bit
Supply Voltage-Min (Vsup) 0.8V
Power Supplies 1.2/2.5V
Supply Voltage-Max (Vsup) 2.7V
Pin Count 56
Base Part Number 74AUC16501
Terminal Pitch 0.5mm
Supply Voltage 1.2V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 0.8V~2.7V
Technology CMOS
Packing Method TAPE AND REEL
HTS Code 8542.39.00.01
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 56
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Pbfree Code yes
JESD-609 Code e4
Series 74AUC
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C
Physical
Number of Pins 56
Package / Case 56-TFSOP (0.240, 6.10mm Width)
Mounting Type Surface Mount
Mount Surface Mount
