SN74ALVCHR16409GR
RoHS
RoHS compliant
RoHS compliantPackage 56-TFSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Logic - Universal Bus Functions
Description
GULL WING Surface Mount ROHS3Compliant DUAL Universal Bus Exchanger -40C~85C 12mA 12mA 1.65V~3.6V 0.5mm
PDF
/
Buying Options
Total Price: USD $7.16
Unit Price: USD $7.1632
≥1 USD $7.1632
Inventory: 2046
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Logic Type Universal Bus Exchanger
Current - Output High, Low 12mA 12mA
Output Characteristics 3-STATE WITH SERIES RESISTOR
Family ALVC/VCX/A
Turn On Delay Time 7.8 ns
Quiescent Current 40μA
Propagation Delay 6.2 ns
Number of Bits 9
Number of Ports 4
Number of Circuits 9-Bit, 4-Port
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 3.6V
Polarity Non-Inverting
Number of Elements 1
Number of Outputs 18
Pin Count 56
Base Part Number 74ALVCHR16409
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1.65V~3.6V
Technology CMOS
Subcategory Other Logic ICs
Number of Terminations 56
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74ALVCHR
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C
Physical
Weight 252.792698mg
Number of Pins 56
Package / Case 56-TFSOP (0.240, 6.10mm Width)
Mounting Type Surface Mount
Mount Surface Mount
