SN74ALVCH16524DGGR
RoHS
RoHS compliant
RoHS compliantPackage 56-TFSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Logic - Universal Bus Functions
Description
GULL WING INDEPENDENT CONTROL Surface Mount ROHS3Compliant Universal Bus Transceiver -40C~85C 24mA 24mA 1.65V~3.6V 0.5mm
PDF
/
Buying Options
Total Price: USD $42.29
Unit Price: USD $42.29495
≥1 USD $42.29495
≥10 USD $34.7035
≥100 USD $33.61955
≥500 USD $32.53465
≥1000 USD $31.4507
Inventory: 1327
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Translation N/A
Control Type INDEPENDENT CONTROL
Trigger Type POSITIVE EDGE
Prop. Delay@Nom-Sup 3.2 ns
Max I(ol) 0.024 A
Logic Type Universal Bus Transceiver
Current - Output High, Low 24mA 24mA
Output Characteristics 3-STATE
Direction Bidirectional
Logic Function Transceiver
Family ALVC/VCX/A
Turn On Delay Time 6.3 ns
Propagation Delay 6.2 ns
Number of Bits 18
Number of Ports 2
Number of Circuits 18-Bit
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 3.6V
Polarity Non-Inverting
Number of Elements 1
Qualification Status Not Qualified
Pin Count 56
Base Part Number 74ALVCH16524
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1.65V~3.6V
Technology CMOS
Packing Method TAPE AND REEL
Additional Feature B TO A DATA FLOW IS THROUGH A 4 STAGE PIPELINE OR THROUGH A SINGLE REGISTER
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 56
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series 74ALVCH
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C
Physical
Weight 252.792698mg
Number of Pins 56
Package / Case 56-TFSOP (0.240, 6.10mm Width)
Mounting Type Surface Mount
Mount Surface Mount
