SN74ABT16501DLRG4
RoHS
/
Package SSOP
Category Integrated Circuits (ICs) / Logic - Universal Bus Functions
Description
Nickel/Palladium/Gold (Ni/Pd/Au) 1 BICMOS SSOP universal bus function 4ns 18.41mm 5.5V -32mA
PDF
/
Buying Options
Total Price: USD $3.84
Unit Price: USD $3.8418
≥1 USD $3.8418
≥10 USD $3.15305
≥100 USD $3.05425
≥500 USD $2.95545
≥1000 USD $2.8576
Inventory: 7689
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 7.49mm
Length 18.41mm
Height 2.59mm
Technical
Translation N/A
Power Supply Current-Max (ICC) 76mA
Control Type INDEPENDENT CONTROL
Low Level Output Current 64mA
High Level Output Current -32mA
Trigger Type POSITIVE EDGE
Prop. Delay@Nom-Sup 4 ns
Max I(ol) 0.064 A
Output Characteristics 3-STATE
Direction Bidirectional
Logic Function Transceiver
Family ABT
Turn On Delay Time 4.5 ns
Propagation Delay 4.5 ns
Number of Bits 18
Current - Output 64mA
Number of Ports 2
Load Capacitance 50pF
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Number of Circuits 1
Temperature Grade INDUSTRIAL
Power Supplies 5V
Polarity Non-Inverting
Operating Supply Voltage 5V
Pin Count 56
Terminal Pitch 0.635mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Packing Method TAPE AND REEL
Additional Feature WITH INDEPENDENT OUTPUT ENABLE FOR EACH DIRECTION
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 56
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e4
Physical
Weight 689.999043mg
Number of Pins 56
Package / Case SSOP
Mount Surface Mount
Alternative Model
