74LVTH16501MEA
RoHS
RoHS compliant
RoHS compliantPackage 56-BSSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Universal Bus Functions
Description
MATTE TIN 18-Bit BICMOS Universal Bus Transceiver universal bus function 6.2ns 18.415mm 2.7V~3.6V 32mA 64mA
PDF
/
Buying Options
Total Price: USD $1.14
Unit Price: USD $1.144
≥1 USD $1.144
Inventory: 1183
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Length 18.415mm
Height Seated (Max) 2.74mm
Technical
Propagation Delay (tpd) 6.2 ns
Output Polarity TRUE
Logic Type Universal Bus Transceiver
Current - Output High, Low 32mA 64mA
Output Characteristics 3-STATE
Family LVT
Number of Bits 18
Number of Ports 2
Number of Circuits 18-Bit
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status COMMERCIAL
JESD-30 Code R-PDSO-G56
Pin Count 56
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.635mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~3.6V
Technology BICMOS
Terminal Finish MATTE TIN
Number of Terminations 56
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series 74LVTH
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 56-BSSOP (0.295, 7.50mm Width)
Mounting Type Surface Mount
