74LVTH16501MTDX
RoHS
/
Package 56-TFSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Logic - Universal Bus Functions
Description
Surface Mount RoHS Compliant Transceiver Lead Free Universal Bus Transceiver -40C~85C 32mA 64mA 2.7V~3.6V 5.6ns
PDF
/
Buying Options
Total Price: USD $1.14
Unit Price: USD $1.144
≥1 USD $1.144
Inventory: 15403
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 56-TFSOP (0.240, 6.10mm Width)
Number of Pins 56
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 74LVTH
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Supply 2.7V~3.6V
Base Part Number 74LVTH16501
Operating Supply Voltage 3.3V
Number of Elements 1
Polarity Non-Inverting
Number of Channels 18
Number of Circuits 18-Bit
Propagation Delay 5.6 ns
Turn On Delay Time 6.6 ns
Logic Function Transceiver
Current - Output High, Low 32mA 64mA
Logic Type Universal Bus Transceiver
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
