SN74LVC2T45DCTR
RoHS
RoHS compliant
RoHS compliantPackage 8-LSSOP, 8-MSOP (0.110, 2.80mm Width)
Category Integrated Circuits (ICs) / Logic - Translators, Level Shifters
Description
e4 ACTIVE (Last Updated: 5days ago) 74LVC2T45 N/A level shifter translator 45.2ns 1.8V 23.388357mg -32mA
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.69436
≥1 USD $0.69436
≥10 USD $0.65506
≥100 USD $0.61798
≥500 USD $0.583
≥1000 USD $0.55
≥3000 USD $0.51887
Inventory: 35230
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.29mm
Width 2.8mm
Length 2.95mm
Height 1.3mm
Technical
Voltage - VCCB 1.65V~5.5V
Voltage - VCCA 1.65V~5.5V
Translator Type Voltage Level
Ambient Temperature Range High 85°C
Max Junction Temperature (Tj) 150°C
Translation N/A
Power Supply Current-Max (ICC) 0.004mA
Control Type COMMON CONTROL
Low Level Output Current 32mA
Channel Type Bidirectional
High Level Output Current -32mA
Logic IC Type BUS TRANSCEIVER
Output Characteristics 3-STATE
Number of Inputs 1
Data Rate 420Mbps
Logic Function Transceiver, Translator
Family LVC/LCX/Z
Turn On Delay Time 17.7 ns
Quiescent Current 3μA
Propagation Delay 45.2 ns
Number of Bits 2
Output Current 32mA
Number of Ports 2
Min Supply Voltage 1.65V
Max Supply Voltage 5.5V
Number of Circuits 1
Number of Channels 2
Power Supplies 3.3V
Polarity Non-Inverting
Output Type Tri-State, Non-Inverted
Pin Count 8
Base Part Number 74LVC2T45
Terminal Pitch 0.65mm
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TR
Subcategory Bus Driver/Transceivers
Additional Feature TWO SEPARATE CONFIGURABLE POWER SUPPLY FOR PORT A AND PORT B
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74LVC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 23.388357mg
Number of Pins 8
Surface Mount YES
Package / Case 8-LSSOP, 8-MSOP (0.110, 2.80mm Width)
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
