SN74AVCH4T245PWE4
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Translators, Level Shifters
Description
e4 ACTIVE (Last Updated: 1week ago) 74AVCH4T245 Nickel/Palladium/Gold (Ni/Pd/Au) level shifter translator 2.9ns 1.5V 61.887009mg -12mA
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8056
≥1 USD $0.8056
≥10 USD $0.6612
≥100 USD $0.6403
≥500 USD $0.62035
≥1000 USD $0.59945
≥500 USD $0.5377
Inventory: 138697
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Number of Pins 16
Weight 61.887009mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series 74AVCH
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature TWO SEPARATE CONFIGURABLE POWER SUPPLY RAILS FOR PORT A AND PORT B
Subcategory Bus Driver/Transceivers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 1.5V
Base Part Number 74AVCH4T245
Pin Count 16
Output Type Tri-State, Non-Inverted
Polarity Non-Inverting
Number of Channels 1
Number of Circuits 2
Max Supply Voltage 3.6V
Min Supply Voltage 1.2V
Number of Ports 2
Output Current 12mA
Number of Bits 4
Propagation Delay 2.9 ns
Turn On Delay Time 10.3 ns
Family AVC
Logic Function Transceiver, Translator
Data Rate 380Mbps
Output Characteristics 3-STATE
Logic IC Type BUS TRANSCEIVER
Prop. Delay@Nom-Sup 6.3 ns
High Level Output Current -12mA
Channel Type Bidirectional
Low Level Output Current 12mA
Control Type COMMON CONTROL
Translator Type Voltage Level
Voltage - VCCA 1.2V~3.6V
Voltage - VCCB 1.2V~3.6V
Dimensions
Height 1.2mm
Length 5mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
