MC10H601FN
RoHS
/
Package 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Logic - Translators, Level Shifters
Description
Unidirectional TRUE Non-RoHS Compliant QUAD Mixed Signal Translator 0C~85C TA 4.57mm 5V
PDF
/
Buying Options
Total Price: USD $1.52
Unit Price: USD $1.52095
≥1 USD $1.52095
≥10 USD $1.2483
≥100 USD $1.20935
≥500 USD $1.1704
≥1000 USD $1.13145
Inventory: 1145
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Height Seated (Max) 4.57mm
Technical
Output Latch or Register NONE
Channels per Circuit 9
Input Signal ECL
Translator Type Mixed Signal
Output Signal TTL
Negative Supply Voltage-Nom -5.2V
Channel Type Unidirectional
Output Polarity TRUE
Output Characteristics 3-STATE
Number of Bits 1
Number of Circuits 1
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Output Type Tri-State, Non-Inverted
Qualification Status COMMERCIAL
JESD-30 Code S-PQCC-J28
Pin Count 28
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 5V
Number of Functions 9
Peak Reflow Temperature (Cel) 240
Terminal Form J BEND
Terminal Position QUAD
Terminal Finish TIN LEAD
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Series 10H
Packaging Tube
Operating Temperature 0°C~85°C TA
Physical
Surface Mount YES
Package / Case 28-LCC (J-Lead)
Mounting Type Surface Mount
