MC10H680FNG
RoHS
/
Package 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Logic - Translators, Level Shifters
Description
e3 10H680 Tin (Sn) ECL level shifter translator 4.8ns 5V -15mA 0C~75C TA
PDF
/
Buying Options
Total Price: USD $34.99
Unit Price: USD $34.993254
≥1 USD $34.993254
≥10 USD $33.012497
≥100 USD $31.143868
≥500 USD $29.381005
≥1000 USD $27.717931
Inventory: 1145
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 28-LCC (J-Lead)
Surface Mount YES
Number of Pins 28
Technical
Operating Temperature 0°C~75°C TA
Packaging Tube
Published 2006
Series 10H
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
ECCN Code EAR99
Terminal Finish Tin (Sn)
Technology ECL
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 10H680
Pin Count 28
Qualification Status Not Qualified
Output Type Differential, Single-Ended
Polarity Non-Inverting
Number of Circuits 1
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Number of Bits 1
Propagation Delay 4.8 ns
Logic Function Transceiver
Output Characteristics 3-STATE
High Level Output Current -15mA
Channel Type Bidirectional
Low Level Output Current 48mA
Negative Supply Voltage-Nom -5.2V
Output Signal TTL
Translator Type Mixed Signal
Input Signal ECL
Channels per Circuit 4
Output Latch or Register NONE
