MC100EPT25DTG
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Logic - Translators, Level Shifters
Description
e3 ACTIVE (Last Updated: 2days ago) 100EPT25 Tin (Sn) level shifter translator 1.6ns 3.3V 157.991892mg -3mA
PDF
/
Buying Options
Total Price: USD $10.89
Unit Price: USD $10.8856
≥1 USD $10.8856
≥10 USD $10.00648
≥100 USD $9.592
≥500 USD $8.036424
≥1000 USD $7.51799
≥3000 USD $6.999502
Inventory: 196
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.1mm
Length 3.1mm
Height 950μm
Technical
Input Signal ECL
Translator Type Mixed Signal
Output Signal LVTTL
Negative Supply Voltage-Nom -3.3V
Low Level Output Current 24mA
Channel Type Unidirectional
High Level Output Current -3mA
Output Polarity TRUE
Rise Time 459 ps
Halogen Free Halogen Free
Output Characteristics TOTEM-POLE
Number of Inputs 2
Logic Function Translator
Turn On Delay Time 1.6 ns
Propagation Delay 1.6 ns
Number of Bits 1
Output Current 24mA
Min Supply Voltage 3V
Max Supply Voltage 3.6V
Number of Channels 1
Power Supplies -4.5V
Output Type Non-Inverted
Pin Count 8
Base Part Number 100EPT25
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology ECL
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 100EPT
Published 2000
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Weight 157.991892mg
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 4 Weeks
