MC100EPT22DTG

ON Semiconductor
RoHS
RoHS RoHS compliant
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Logic - Translators, Level Shifters
Description e3 ACTIVE (Last Updated: 2days ago) 100EPT22 LVCMOS LVTTL level shifter translator 675ps 3.3V 157.991892mg -50mA
PDF
/
Buying Options
Total Price: USD $10.23
Unit Price: USD $10.2344
≥1 USD $10.2344
≥10 USD $9.24352
≥100 USD $8.81408
≥500 USD $7.309104
≥1000 USD $6.664178
≥3000 USD $6.234254
Inventory: 3180
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)

Physical

Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Number of Pins 8
Weight 157.991892mg

Technical

Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2000
Series 100EPT
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
ECCN Code EAR99
Technology ECL
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 2
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Base Part Number 100EPT22
Pin Count 8
Output Type Differential
Operating Supply Voltage 3.3V
Number of Channels 2
Number of Circuits 1
Max Supply Voltage 3.6V
Min Supply Voltage 3V
Output Current 50mA
Number of Bits 1
Propagation Delay 675 ps
Turn On Delay Time 700 ps
Logic Function Translator
Halogen Free Halogen Free
Rise Time 110 ps
Output Polarity COMPLEMENTARY
High Level Output Current -50mA
Channel Type Unidirectional
Low Level Output Current 50mA
Output Signal LVPECL
Translator Type Mixed Signal
Input Signal LVCMOS, LVTTL
Delay-Max 0.7 ns

Dimensions

Height 950μm
Length 3.1mm
Width 3.1mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
