SN74S1050N
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
IC 12-BIT BUS TERM ARRAY16-DIP
PDF
/
Buying Options
Total Price: USD $2.89
Unit Price: USD $2.890703
≥1 USD $2.890703
≥10 USD $2.727076
≥100 USD $2.572715
≥500 USD $2.427086
≥1000 USD $2.289704
Inventory: 1320
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Length 19.305mm
Height Seated (Max) 5.08mm
Technical
Number of Signal Lines 12
Max Repetitive Reverse Voltage (Vrrm) 7V
Peak Reverse Current 5μA
Reverse Recovery Time 16 ns
Differential Output NO
Forward Voltage 1.2V
Logic Type Schottky Barrier Diode Bus-Termination Array
Forward Current 170mA
Number of Bits 12
Qualification Status Not Qualified
Pin Count 16
Base Part Number 74S1050
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
HTS Code 8542.39.00.01
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 74S
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Number of Pins 16
Package / Case 16-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
