SN74BCT8244ADW
RoHS
RoHS compliant
RoHS compliantPackage 24-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
TEXAS INSTRUMENTS SN74BCT8244ADW Scan Test Device with Octal Buffers, 4.5 V to 5.5 V, SOIC-24
PDF
/
Buying Options
Total Price: USD $7.69
Unit Price: USD $7.6912
≥1 USD $7.6912
≥10 USD $7.0664
≥100 USD $6.773536
≥500 USD $6.446
Inventory: 70
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 15.4mm
Height 2.65mm
Technical
Translation N/A
Count Direction UNIDIRECTIONAL
Control Type ENABLE LOW
Low Level Output Current 64mA
High Level Output Current -15mA
Max I(ol) 0.064 A
Logic Type Scan Test Device with Buffers
Output Characteristics 3-STATE
Logic Function Buffer
Family BCT/FBT
Turn On Delay Time 29 ns
Quiescent Current 35mA
Propagation Delay 29 ns
Number of Bits 4
Number of Ports 2
Load Capacitance 50pF
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Polarity Non-Inverting
Number of Elements 2
Number of Outputs 8
Pin Count 24
Base Part Number 74BCT8244
Supply Voltage 4.5V~5.5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Bus Driver/Transceivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74BCT
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Weight 624.398247mg
Number of Pins 24
Package / Case 24-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
Alternative Model
