SN74BCT8240ADWRE4
RoHS
RoHS compliant
RoHS compliantPackage 24-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
IC SCAN TEST DEVICE BUFF 24-SOIC
PDF
/
Inventory: 8899
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Length 15.4mm
Height Seated (Max) 2.65mm
Technical
Power Supply Current-Max (ICC) 52mA
Control Type ENABLE LOW
Prop. Delay@Nom-Sup 9 ns
Max I(ol) 0.064 A
Output Polarity INVERTED
Logic Type Scan Test Device with Inverting Buffers
Output Characteristics 3-STATE
Logic Function Inverting
Family BCT/FBT
Number of Bits 8
Number of Ports 2
Power Supplies 5V
Operating Supply Voltage 5.5V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G24
Pin Count 24
Base Part Number 74BCT8240
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 4.5V~5.5V
Number of Functions 2
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Packing Method TAPE AND REEL
Subcategory Bus Driver/Transceivers
Additional Feature SUPPORTS IEEE STANDARD 1149.1-1990 BOUNDARY SCAN
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 74BCT
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Package / Case 24-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Alternative Model
