SN74AS181ADWRG4

Texas Instruments
RoHS
RoHS RoHS compliant
Package 24-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description IC ARITHMETIC LOGIC UNIT 24SOIC
PDF
/
Inventory: 1767
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 7.52mm
Length 15.4mm
Height 2.35mm

Technical

Power Supply Current-Max (ICC) 200mA
Low Level Output Current 48mA
High Level Output Current -3mA
Output Polarity INVERTED
Logic Type Arithmetic Logic Unit
Output Characteristics 3-STATE
Family AS
Propagation Delay 11 ns
Number of Bits 4
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Number of Circuits 1
Power Supplies 5V
Qualification Status Not Qualified
Pin Count 24
Base Part Number 74AS181
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 4.5V~5.5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology TTL
Subcategory Arithmetic Circuits
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 74AS
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C

Physical

Weight 1.098005g
Number of Pins 24
Package / Case 24-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
