SN74ACT1284PW

Texas Instruments
RoHS
RoHS RoHS compliant
Package 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description TEXAS INSTRUMENTS SN74ACT1284PW 7-Bit Bus Interfaces with 3-State Outputs, 7 Channel, 4.7 V to 5.5 V, TSSOP-20
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.9196
≥1 USD $0.9196
≥10 USD $0.75525
≥100 USD $0.7315
≥500 USD $0.70775
≥1000 USD $0.684
Inventory: 16795
Minimum: 1
-
+

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Number of Pins 20
Weight 76.997305mg

Technical

Operating Temperature 0°C~70°C
Packaging Tube
Series 74ACT
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 4
Supply Voltage 4.5V~5.5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74ACT1284
Pin Count 20
Qualification Status Not Qualified
Max Supply Voltage 5.5V
Min Supply Voltage 4.7V
Nominal Supply Current 1.5mA
Output Current 14mA
Number of Bits 7
Logic Function Transceiver
Logic Type IEEE STD 1284 Translation Transceiver
Differential Output NO
Input Characteristics SCHMITT TRIGGER
Number of Transmitters 2

Dimensions

Length 6.5mm
Width 4.4mm

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
