SN74ACT1284DWR
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
IC 7BIT BUS INTERFACE 3ST 20SOIC
PDF
/
Buying Options
Total Price: USD $0.76
Unit Price: USD $0.76285
≥1 USD $0.76285
≥10 USD $0.62605
≥100 USD $0.6061
≥500 USD $0.58615
≥1000 USD $0.56715
≥1000 USD $0.50825
Inventory: 19002
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Weight 500.709277mg
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Series 74ACT
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 4.5V~5.5V
Base Part Number 74ACT1284
Pin Count 20
Max Supply Voltage 5.5V
Min Supply Voltage 4.7V
Nominal Supply Current 1.5mA
Output Current 14mA
Number of Bits 7
Logic Function Transceiver
Output Characteristics 3-STATE
Logic Type IEEE STD 1284 Translation Transceiver
Differential Output NO
Output Polarity TRUE
Input Characteristics SCHMITT TRIGGER
Supply Voltage1-Nom 5V
Number of Receivers 4
Number of Transmitters 2
Dimensions
Height 2.65mm
Length 12.8mm
Width 7.5mm
Thickness 2.35mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
