SN74ABTE16245DLG4
RoHS
RoHS compliant
RoHS compliantPackage 48-BSSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
IC 16BIT I-WS BUS TXRX 48-SSOP
PDF
/
Buying Options
Total Price: USD $11.28
Unit Price: USD $11.277811
≥1 USD $11.277811
≥200 USD $4.36408
≥500 USD $4.211783
≥1000 USD $4.135635
Inventory: 1223
Minimum: 1
-
+
Technical Details
Technical
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 48
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 4.5V~5.5V
Terminal Pitch 0.635mm
Base Part Number 74ABTE16245
Pin Count 48
Operating Supply Voltage 5V
Number of Elements 2
Polarity Non-Inverting
Power Supplies 5V
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Load Capacitance 50pF
Number of Ports 2
Output Current 90mA
Number of Bits 16
Propagation Delay 7.3 ns
Quiescent Current 38mA
Turn On Delay Time 7.3 ns
Family ABTE/ETL
Logic Function Transceiver
Direction Bidirectional
Output Characteristics 3-STATE
Logic Type Incident-Wave Switching Bus Transceivers
Max I(ol) 0.09 A
Pbfree Code yes
JESD-609 Code e4
Series 74ABTE
Packaging Tube
Operating Temperature -40°C~85°C
High Level Output Current -60mA
Low Level Output Current 90mA
Control Type COMMON CONTROL
Schmitt Trigger No
Translation BTL & TTL
Physical
Weight 600.301152mg
Number of Pins 48
Package / Case 48-BSSOP (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
