SN74ABT8952DW
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
LOGIC, SCAN-TEST-DEV/XCVR, 28SOIC - More Details
PDF
/
Buying Options
Total Price: USD $45.04
Unit Price: USD $45.037845
≥1 USD $45.037845
≥10 USD $42.488529
≥100 USD $40.083522
≥500 USD $37.814643
≥1000 USD $35.674189
Inventory: 1416
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Translation N/A
Control Type INDEPENDENT CONTROL
Trigger Type POSITIVE EDGE
Prop. Delay@Nom-Sup 6.3 ns
Max I(ol) 0.064 A
Evaluation Kit Yes
Logic Type Scan Test Device with Registered Bus Transceiver
Output Characteristics 3-STATE
Direction Bidirectional
Logic Function AND, Transceiver
Family ABT
Turn On Delay Time 13.5 ns
Quiescent Current 30mA
Propagation Delay 13.5 ns
Number of Bits 8
Number of Ports 2
Load Capacitance 50pF
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Number of Circuits 8
Power Supplies 5V
Polarity Non-Inverting
Number of Elements 1
Pin Count 28
Base Part Number 74ABT8652
Supply Voltage 4.5V~5.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Bus Driver/Transceivers
Additional Feature WITH INDEPENDENT OUTPUT ENABLE FOR EACH DIRECTION; WITH CLOCK ENABLE
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 74ABT
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 730.794007mg
Number of Pins 28
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
