SN74ABT8652DWR
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
IC SCAN TEST DEVICE 28-SOIC
PDF
/
Buying Options
Total Price: USD $12.52
Unit Price: USD $12.522177
≥1 USD $12.522177
≥10 USD $11.813377
≥100 USD $11.144693
≥500 USD $10.513865
≥1000 USD $9.91874
Inventory: 1256
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 74ABT
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
Additional Feature INDEPENDENT OUTPUT ENABLE FOR EACH DIRECTION; MULTIPLEXED TRANSMISSION OF REGISTERED/REAL TIME DATA
Subcategory Bus Driver/Transceivers
Packing Method TAPE AND REEL
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 4.5V~5.5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74ABT8652
Pin Count 28
Qualification Status Not Qualified
Polarity Non-Inverting
Power Supplies 5V
Number of Circuits 1
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Load Capacitance 50pF
Number of Ports 2
Number of Bits 8
Propagation Delay 5.3 ns
Family ABT
Logic Function AND, Transceiver
Output Characteristics 3-STATE
Logic Type Scan Test Device with Bus Transceiver and Registers
Max I(ol) 0.064 A
Prop. Delay@Nom-Sup 5.5 ns
Trigger Type POSITIVE EDGE
High Level Output Current -32mA
Low Level Output Current 64mA
Control Type INDEPENDENT CONTROL
Count Direction BIDIRECTIONAL
Translation N/A
Dimensions
Height Seated (Max) 2.65mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
