CD74ACT283E
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
TEXAS INSTRUMENTS CD74ACT283ELOGIC, 4-BIT BIN FILL ADDER, 16DIP
PDF
/
Buying Options
Total Price: USD $0.74
Unit Price: USD $0.7392
≥1 USD $0.7392
Inventory: 6829
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 3.9mm
Width 6.35mm
Length 19.3mm
Height 5.08mm
Technical
Power Supply Current-Max (ICC) 0.08mA
Low Level Output Current 24mA
High Level Output Current -24mA
Max I(ol) 0.075 A
Output Polarity TRUE
Logic Type Binary Full Adder with Fast Carry
Max Input Voltage 2V
Logic Function Binary Full Adder
Min Input Voltage 800mV
Family ACT
Turn On Delay Time 18.2 ns
Quiescent Current 8μA
Propagation Delay 18.2 ns
Number of Bits 4
Load Capacitance 50pF
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Number of Channels 1
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 16
Base Part Number 74ACT283
Supply Voltage 4.5V~5.5V
Number of Functions 1
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 120mW
Subcategory Arithmetic Circuits
Additional Feature FULL ADDER; WITH INTERNAL CARRY LOOKAHEAD
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series 74ACT
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Weight 951.693491mg
Number of Pins 16
Package / Case 16-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
