CD40117BMT
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
LOGIC, DUAL 4BIT TERM, 14SO, RL250 - More Details
PDF
/
Inventory: 7841
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 3.9mm
Height Seated (Max) 1.75mm
Technical
Number of Signal Lines 4
Interface IC Type OTHER TERMINATOR
Differential Output NO
Logic Type Programmable Terminator
Number of Bits 8
Min Supply Voltage 3V
Max Supply Voltage 18V
Power Supplies 5/15V
Max Output Current 250μA
Qualification Status Not Qualified
Pin Count 14
Base Part Number CD40117
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 3V~18V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Bus Terminators
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 4000B
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Weight 129.387224mg
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
