74F181PC
RoHS
/
Package 24-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
ALU, F/FAST SERIES, 4-BIT, TTL
PDF
/
Buying Options
Total Price: USD $2.62
Unit Price: USD $2.621861
≥1 USD $2.621861
≥195 USD $1.046381
≥495 USD $1.010933
≥1005 USD $0.993865
Inventory: 3658
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 31.915mm
Technical
Propagation Delay (tpd) 15 ns
Logic Type Arithmetic Logic Unit
Family F/FAST
Number of Bits 4
Qualification Status Not Qualified
Pin Count 24
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Supply Voltage 4.5V~5.5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology TTL
Additional Feature CAPABLE OF 16 LOGIC AND ARITHMETIC OPERATIONS
Number of Terminations 24
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
Series 74F
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount NO
Package / Case 24-DIP (0.600, 15.24mm)
Mounting Type Through Hole
