MC10H332FNR2G
RoHS
/
Package 20-LCC (J-Lead)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
Buffers & Line Drivers Dual Bus w/ 4:1 Mux
PDF
/
Inventory: 6852
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Min Supply Voltage 8V
Number of Ports 2
Nominal Supply Current 115mA
Number of Bits 2
Family 10H
Logic Function AND, Receiver
Qualification Status Not Qualified
Pin Count 20
Base Part Number 10H332
Time@Peak Reflow Temperature-Max (s) 40
Reach Compliance Code unknown
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form J BEND
Terminal Position QUAD
Technology ECL
Packing Method TAPE AND REEL
Subcategory Multiplexer/Demultiplexers
Additional Feature WITH 4:1 OUTPUT MULTIPLEXERS
Terminal Finish Tin (Sn)
Number of Terminations 20
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e3
Series 10H
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature 0°C~75°C
Propagation Delay (tpd) 3 ns
Prop. Delay@Nom-Sup 4.5 ns
Output Polarity TRUE
Logic Type Driver/Receiver
Output Characteristics 3-STATE
Physical
Number of Pins 20
Package / Case 20-LCC (J-Lead)
Mounting Type Surface Mount
Mount Surface Mount
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 8.965mm
Length 8.965mm
Height Seated (Max) 4.57mm
