MC100EP16VCMNR4G
RoHS
/
Package 8-VFDFN Exposed Pad
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
IC RCVR/DVR 5V DIFF 8-DFN
PDF
/
Buying Options
Total Price: USD $5.08
Unit Price: USD $5.079057
≥1 USD $5.079057
≥10 USD $4.791559
≥100 USD $4.520338
≥500 USD $4.264474
≥1000 USD $4.02309
Inventory: 1102
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 2mm
Length 2mm
Technical
Number of Transmitters 1
Transmit Delay-Max 0.4 ns
Negative Supply Voltage-Nom -4.5V
Receive Delay-Max 0.4 ns
Interface Standard GENERAL PURPOSE
Receiver Number of Bits 1
Driver Number of Bits 1
Interface IC Type LINE TRANSCEIVER
Differential Output YES
Logic Type Differential Receiver/Driver
Halogen Free Halogen Free
Logic Function Receiver
Nominal Supply Current 54mA
Min Supply Voltage 3V
Max Supply Voltage 5.5V
Power Supplies -4.5V
Qualification Status Not Qualified
Pin Count 8
Base Part Number 100EP16
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.5mm
Supply Voltage 3V~5.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Technology ECL
Additional Feature CAN ALSO OPERATE WITH -3V TO -5.5V SUPPLY IN NECL MODE
Terminal Finish Nickel/Gold/Palladium (Ni/Au/Pd)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 100EP
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-VFDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
