MC100EP16VBDG
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
IC RCVR/DRVR ECL DIFF 5V 8SOIC
PDF
/
Buying Options
Total Price: USD $9.92
Unit Price: USD $9.91714
≥1 USD $9.91714
≥10 USD $9.355794
≥100 USD $8.82622
≥500 USD $8.326621
≥1000 USD $7.855299
Inventory: 1162
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2006
Series 100EP
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Additional Feature CAN ALSO OPERATE WITH -3V TO -5.5V SUPPLY IN NECL MODE
Technology ECL
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V~5.5V
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 100EP16
Pin Count 8
Power Supplies -4.5V
Max Supply Voltage 5.5V
Min Supply Voltage 3V
Nominal Supply Current 52mA
Logic Function Receiver
Halogen Free Halogen Free
Logic Type Differential Receiver/Driver
Differential Output YES
Interface IC Type LINE TRANSCEIVER
Driver Number of Bits 1
Receiver Number of Bits 1
Interface Standard GENERAL PURPOSE
Receive Delay-Max 0.4 ns
Negative Supply Voltage-Nom -4.5V
Transmit Delay-Max 0.4 ns
Number of Transmitters 1
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
