MC100EP116FAR2
RoHS
/
Package 32-LQFP
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
IC TCVR/DRVR HEX DIFF ECL 32LQFP
PDF
/
Buying Options
Total Price: USD $6.11
Unit Price: USD $6.1072
≥1 USD $6.1072
Inventory: 6065
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 7mm
Length 7mm
Technical
Transmit Delay-Max 0.34 ns
Negative Supply Voltage-Nom -4.5V
Receive Delay-Max 0.34 ns
Interface Standard GENERAL PURPOSE
Interface IC Type LINE TRANSCEIVER
Differential Output YES
Logic Type Differential Receiver/Driver
Logic Function AND, Receiver
Number of Bits 6
Nominal Supply Current 95mA
Power Supplies -4.5V
Operating Supply Voltage 5.5V
Pin Count 32
Base Part Number 100EP116
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.8mm
Supply Voltage 3V~5.5V
Number of Functions 6
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position QUAD
Technology ECL
Subcategory Line Driver or Receivers
HTS Code 8542.39.00.01
Additional Feature CAN ALSO OPERATE WITH -3V TO -5.5V SUPPLY IN NECL MODE
Terminal Finish Tin/Lead (Sn80Pb20)
ECCN Code EAR99
Number of Terminations 32
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
JESD-609 Code e0
Series 100EP
Published 2006
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C
Physical
Number of Pins 32
Package / Case 32-LQFP
Mounting Type Surface Mount
Mount Surface Mount
