74F181SPC
RoHS
/
Package 24-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
IC ARITHMETIC LOGIC 4BIT 24-DIP
PDF
/
Buying Options
Total Price: USD $6.37
Unit Price: USD $6.3712
≥1 USD $6.3712
Inventory: 1190
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 24-DIP (0.300, 7.62mm)
Number of Pins 24
Supplier Device Package 24-PDIP
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Series 74F
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Supply Voltage 4.5V~5.5V
Base Part Number 74F181
Output Voltage 5.5V
Number of Circuits 1
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Output Current 65mA
Number of Bits 4
Propagation Delay 12 ns
Logic Type Arithmetic Logic Unit
High Level Output Current -1mA
Low Level Output Current 20mA
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
