M74HC257RM13TR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Signal Switches, Multiplexers, Decoders
Description
HC/UH e4 M74HC257 4x 2:1 multiplexer circuit 24ns 500mW 2/6V 9.9mm
PDF
/
Buying Options
Total Price: USD $9.72
Unit Price: USD $9.7223
≥1 USD $9.7223
≥10 USD $7.97715
≥100 USD $7.72825
≥500 USD $7.47935
≥1000 USD $7.2295
Inventory: 1147
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 9.9mm
Technical
Independent Circuits 1
Voltage Supply Source Single Supply
Prop. Delay@Nom-Sup 30 ns
Max I(ol) 0.006 A
Supply Type Single
Current - Output High, Low 7.8mA 7.8mA
Output Characteristics 3-STATE
Number of Inputs 8
Logic Function Multiplexer, Mux
Family HC/UH
Propagation Delay 24 ns
Throw Configuration DPST
Power Dissipation 500mW
Load Capacitance 50pF
Number of Circuits 4
Supply Voltage-Min (Vsup) 2V
Power Supplies 2/6V
Supply Voltage-Max (Vsup) 6V
Polarity Inverting
Circuit 4 x 2:1
Number of Outputs 1
Pin Count 16
Base Part Number M74HC257
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 4.5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Packing Method TAPE AND REEL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Multiplexer
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 74HC
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Alternative Model
