74AC257MTR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Signal Switches, Multiplexers, Decoders
Description
AC e3 74AC257 4x 2:1 decoder circuit 6ns 3.3/5V 9.9mm 24mA 24mA
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2147
≥1 USD $0.2147
≥10 USD $0.1767
≥100 USD $0.171
≥500 USD $0.1653
≥1000 USD $0.16055
Inventory: 1181
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 9.9mm
Technical
Independent Circuits 1
Voltage Supply Source Single Supply
Prop. Delay@Nom-Sup 9 ns
Supply Type Single
Current - Output High, Low 24mA 24mA
Output Characteristics 3-STATE
Number of Inputs 8
Logic Function Mux
Family AC
Propagation Delay 6 ns
Throw Configuration DPST
Load Capacitance 50pF
Number of Circuits 4
Supply Voltage-Min (Vsup) 2V
Power Supplies 3.3/5V
Supply Voltage-Max (Vsup) 6V
Polarity Non-Inverting
Circuit 4 x 2:1
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 16
Base Part Number 74AC257
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Supply Voltage 3.3V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Packing Method TAPE AND REEL
Terminal Finish Tin (Sn)
Type Multiplexer
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series 74AC
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
