TPIC6C596PWG4
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
6C TPIC6C596 ROHS3Compliant Tube shift register 80ns 62.99264mg 5V -40C~125C
PDF
/
Buying Options
Total Price: USD $0.6
Unit Price: USD $0.6042
≥1 USD $0.6042
≥10 USD $0.4959
≥100 USD $0.4807
≥500 USD $0.4655
≥1000 USD $0.44935
Inventory: 409797
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Number of Pins 16
Weight 62.99264mg
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Series TPIC
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature PARALLEL OUTPUT IS REGISTERED; UNREGISTERED SERIAL SHIFT RIGHT OUTPUT
Packing Method TR
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Base Part Number TPIC6C596
Function Serial to Parallel, Serial
Output Type Open Drain
Operating Supply Voltage 5V
Power Supplies 5V
Load Capacitance 30pF
Propagation Delay 80 ns
Turn On Delay Time 80 ns
Family 6C
Logic Function Shift Register
Direction Unidirectional
Logic Type Shift Register
Output Polarity TRUE
Number of Bits per Element 8
Trigger Type POSITIVE EDGE
Number of Input Lines 1
Number of Output Lines 9
Dimensions
Height 1.2mm
Length 5mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
