TPIC6B596DWG4
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
6B TPIC6B596 ROHS3Compliant Tube shift register 150ns 537.308512mg 5V -40C~125C
PDF
/
Inventory: 1
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 12.8mm
Height 2.65mm
Technical
Number of Output Lines 9
Number of Input Lines 1
Trigger Type POSITIVE EDGE
Number of Bits per Element 8
Output Polarity TRUE
Logic Type Shift Register
Direction Unidirectional
Logic Function Shift Register
Family 6B
Turn On Delay Time 150 ns
Propagation Delay 150 ns
Load Capacitance 30pF
Power Supplies 5V
Operating Supply Voltage 5V
Output Type Open Drain
Function Serial to Parallel, Serial
Base Part Number TPIC6B596
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Additional Feature PARALLEL OUTPUT IS REGISTERED; UNREGISTERED SERIAL SHIFT RIGHT OUTPUT
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series TPIC
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Weight 537.308512mg
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
