SNJ54LS597FK
RoHS
/
Package /
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
TRUE Contains Lead QUAD Surface Mount shift register 30pF 125C 5.5V 35MHz
PDF
/
Buying Options
Total Price: USD $38.83
Unit Price: USD $38.8344
≥1 USD $38.8344
Inventory: 277
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mount Surface Mount
Number of Pins 20
Technical
Packaging Rail/Tube
Number of Terminations 20
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Additional Feature COMMON I/O PINS; MIXED SERIAL INPUTS; TOTEMPOLE SERIAL OUTPUT
Technology TTL
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 20
Qualification Status Not Qualified
Output Type TTL
Operating Supply Voltage 5V
Number of Elements 1
Temperature Grade MILITARY
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Load Capacitance 30pF
Number of Bits 8
Propagation Delay 60 ns
Family LS
Logic Function Shift Register
Direction Unidirectional
Output Characteristics 3-STATE
Output Polarity TRUE
Logic IC Type PARALLEL IN SERIAL OUT
Max I(ol) 0.024 A
Prop. Delay@Nom-Sup 30 ns
Trigger Type POSITIVE EDGE
Schmitt Trigger No
Power Supply Current-Max (ICC) 53mA
fmax-Min 35 MHz
Dimensions
Height 2.03mm
Length 8.89mm
Width 8.89mm
Thickness 1.83mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
