SN74LS670NS
RoHS
/
Package /
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
RoHS Compliant EAR99 GULL WING Nickel/Palladium/Gold (Ni/Pd/Au) shift register 45ns 10.3mm 4.75V 70C
PDF
/
Buying Options
Total Price: USD $0.91
Unit Price: USD $0.9064
≥1 USD $0.9064
Inventory: 1499
Minimum: 1
-
+
Technical Details
Physical
Surface Mount YES
Technical
JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.39.00.01
Subcategory Other Memory ICs
Technology TTL
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 16
Qualification Status Not Qualified
Operating Temperature (Max) 70°C
Supply Voltage-Max (Vsup) 5.25V
Power Supplies 5V
Temperature Grade COMMERCIAL
Supply Voltage-Min (Vsup) 4.75V
Operating Mode ASYNCHRONOUS
Number of Bits 16
Organization 4X4
Output Characteristics 3-STATE
Memory Width 4
Standby Current-Max 0.05A
Access Time (Max) 45 ns
Parallel/Serial PARALLEL
Memory IC Type STANDARD SRAM
Output Enable NO
Dimensions
Height Seated (Max) 2mm
Length 10.3mm
Width 5.3mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
