SN74LS594NSR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
TRUE DUAL Serial to Parallel Surface Mount Shift Register 0C~70C 5V 20MHz 2mm
PDF
/
Inventory: 4313
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5.3mm
Height Seated (Max) 2mm
Technical
Count Direction RIGHT
fmax-Min 20 MHz
Number of Output Lines 9
Number of Input Lines 1
Trigger Type POSITIVE EDGE
Number of Bits per Element 8
Output Polarity TRUE
Logic Type Shift Register
Logic Function Shift Register
Family LS
Propagation Delay 30 ns
Power Supplies 5V
Operating Supply Voltage 5V
Output Type Push-Pull
Qualification Status Not Qualified
Function Serial to Parallel
Base Part Number 74LS594
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology TTL
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 74LS
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 16
Package / Case 16-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
