SN74LS165ADRG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
LS PARALLEL IN SERIAL OUT RoHS Compliant Tape & Reel (TR) shift register 25ns 139.989945mg 25000000Hz 5.25V
PDF
/
Buying Options
Total Price: USD $0.45
Unit Price: USD $0.45125
≥1 USD $0.45125
≥10 USD $0.3705
≥100 USD $0.35815
≥500 USD $0.34675
≥1000 USD $0.33535
Inventory: 148840
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Max Frequency@Nom-Sup 25000000Hz
fmax-Min 25 MHz
Number of Input Lines 9
Trigger Type POSITIVE EDGE
Logic IC Type PARALLEL IN SERIAL OUT
Output Polarity COMPLEMENTARY
Direction Unidirectional
Logic Function OR, Shift Register
Family LS
Turn On Delay Time 35 ns
Propagation Delay 25 ns
Number of Bits 8
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Temperature Grade COMMERCIAL
Power Supplies 5V
Number of Elements 1
Operating Supply Voltage 5V
Pin Count 16
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology TTL
Subcategory Shift Registers
Additional Feature SISO OPERATION ALSO AVAILABLE
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e4
Packaging Tape & Reel (TR)
Physical
Weight 139.989945mg
Number of Pins 16
Package / Case SOIC
Mount Surface Mount
