SN74LS164NS
RoHS
/
Package /
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
LS SERIAL IN PARALLEL OUT RoHS Compliant TR shift register 32ns 27mA 10.3mm 25000000Hz
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.810147
≥1 USD $0.810147
≥10 USD $0.764287
≥100 USD $0.721029
≥500 USD $0.680214
≥1000 USD $0.64171
Inventory: 9550
Minimum: 1
-
+
Technical Details
Physical
Surface Mount YES
Technical
JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 14
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature GATED SERIAL INPUTS (A AND B)
HTS Code 8542.39.00.01
Subcategory Shift Register
Packing Method TR
Technology TTL
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 14
JESD-30 Code R-PDSO-G14
Qualification Status Not Qualified
Operating Temperature (Max) 70°C
Supply Voltage-Max (Vsup) 5.25V
Power Supplies 5V
Temperature Grade COMMERCIAL
Supply Voltage-Min (Vsup) 4.75V
Load Capacitance 15pF
Number of Bits 8
Family LS
Output Polarity TRUE
Logic IC Type SERIAL IN PARALLEL OUT
Max I(ol) 0.008 A
Prop. Delay@Nom-Sup 32 ns
Trigger Type POSITIVE EDGE
Propagation Delay (tpd) 32 ns
Schmitt Trigger No
Power Supply Current-Max (ICC) 27mA
fmax-Min 25 MHz
Count Direction RIGHT
Max Frequency@Nom-Sup 25000000Hz
Dimensions
Height Seated (Max) 2mm
Length 10.3mm
Width 5.3mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
