SN74HC595DT
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
HC/UH 74HC595 ROHS3Compliant Tape & Reel (TR) shift register 250ns 80muA 141.690917mg 29MHz
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.554044
≥1 USD $0.554044
≥250 USD $0.215316
≥500 USD $0.207438
≥1000 USD $0.2035
Inventory: 1320
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 9.9mm
Height 1.75mm
Technical
Number of Output Lines 10
Schmitt Trigger No
Max Input Current 80μA
Trigger Type POSITIVE EDGE
Number of Bits per Element 8
Output Polarity TRUE
Logic Type Shift Register
Output Characteristics 3-STATE
Direction Unidirectional
Logic Function Shift Register
Family HC/UH
Turn On Delay Time 250 ns
Propagation Delay 34 ns
Number of Circuits 4
Supply Voltage-Min (Vsup) 2V
Power Supplies 2/6V
Supply Voltage-Max (Vsup) 6V
Number of Elements 1
Operating Supply Voltage 5V
Output Type Tri-State
Qualification Status Not Qualified
Function Serial to Parallel, Serial
Base Part Number 74HC595
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 29MHz
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Packing Method TR
Additional Feature PARALLEL OUTPUT IS REGISTERED; UNREGISTERED SERIAL SHIFT RIGHT OUTPUT
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Termination SMD/SMT
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74HC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 141.690917mg
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
