SN74HC164NS
RoHS
/
Package 14-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
HC/UH 74HC164 RoHS Compliant Tube shift register 220ns 0.0052A 2mm 25000000Hz
PDF
/
Buying Options
Total Price: USD $1.01
Unit Price: USD $1.012
≥1 USD $1.012
≥10 USD $0.902
≥100 USD $0.856064
≥500 USD $0.703208
≥1000 USD $0.65736
≥3000 USD $0.580923
Inventory: 1091
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 5.3mm
Height Seated (Max) 2mm
Technical
Max Frequency@Nom-Sup 25000000Hz
Count Direction RIGHT
Schmitt Trigger No
Propagation Delay (tpd) 220 ns
Trigger Type POSITIVE EDGE
Number of Bits per Element 8
Max I(ol) 0.0052 A
Output Polarity TRUE
Logic Type Shift Register
Logic Function Shift Register
Family HC/UH
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 2V
Power Supplies 2/6V
Supply Voltage-Max (Vsup) 6V
Number of Elements 1
Output Type Push-Pull
Qualification Status Not Qualified
Function Serial to Parallel
Base Part Number 74HC164
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Packing Method TR
Additional Feature AND-GATED SERIAL INPUTS (A AND B)
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74HC
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case 14-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Alternative Model
